Overview

Basic Info.

Application	Solar System
Condition	New
Certification	CE
Material	Monocrystalline Silicon
Solar Cell	210*182mm
Type	Customized Solar Panel
Junction Box	Jb with 0.9m Wire and Connector
OEM Order	Acceptble
Frame	Anodized Aluminium Alloy
Cell Material	Monocrystalline Silicon
Main Market	Asia Africa Southeast Asia
Tpt Back Sheet	White or Black, Black Backsheet
Connector	Mc4 Compatible Connector
Back Sheet	TPE Quality Plastic
Transport Package	Pallet
Specification	880*610*30MM
Trademark	OEM
Origin	China
HS Code	8541402000
Production Capacity	1500/Week

Product Description

Electrical Characteristics

·Offer high quality solar panels with very competitive price, both Mono and Poly types, models range from 5Wp to 600Wp; ·ODM&OEM services available; ·Flexible payment terms: T/T, L/C, Western Union; ·Fast delivery time: 7 days for sample order, 15 days for a 20FT container, 20 days for a 40HQ; ·Production capacity: About 200MW per month, and around 1.4GW per year; ·Certified by DEKRA CE and ISO9001, all solar panels meet international quality standards; ·All inquiries and emails would be replied within one hour. (Inquiries and emails sent between 11: 00pm-06: 00am would be replied back in 7 hours) ·All solar panels would be tested before packing, and the test report would come with each panel; ·Various strong package: Single carton, master carton, wooden case, pallet, with foam and protecting corner protection; ·Warranty: All solar panels lifetime more than 25 years, output power no less than 90% in 10 years and no less than 80% in 20 years; ·After-sales warranty: 12 years free replacement if any panel fails to work or output power less than 80%. All fees caused by charged by Ollin Solar. Replacement for one or two pieces couriered by courier, for above 10 pieces shipped by sea (only if customers agree and confirm)

Payment & Shipping

1. Q: Are you a factory or a trading company?

A :We are a professional Solar Panels Manufacturer in China 2.How can we guarantee the products quality? A :Always provide the esteemed buyer a pre-production sample before mass production; Always testing every product before despatching the shipments;3.What products we can supply you? A :Solar panels,inverter,controller,cable,support frame and other solar power systems4. Q: Where is your Manufacturer located? How can I visit there? A :Our factory located in Yuyao NO 12, Yuci North Road, Ningbo City, Zhejiang Province,China5. Q: Can the products pricing be cheaper? A :Of course, you will be offered a a very good discount with large quantities.6. Q: Can print our company's logo on the pv panels? A :Yes! And we accept the OEM&ODM orders.

Electrical Characteristics
STC (Irradiance 1,000W/m2, module temperature 25ºC, AM=1.5)	OL100M-10
Rated Power (Pmax)	100W
Voltage at Pmax (Vmp)	18.1V
Current at Pmax (Imp)	5.55A
Warranted Minimum Pmax	100W
Short-Circuit Current (Isc)	5.99A
Open-Circuit Voltage (Voc)	21.6V
Module Efficiency	19.00%
Operating Module Temperature	-40ºC to + 85ºC
Maximum System Voltage	1,000V(IEC) / 1,000V(UL)
Maximum Series Fuse Rating	15A
Maximum Reverse Current	20.25A
Power Tolerance	0 ~ +5 W

Company Profile

Ollin Solar was founded in 2010, Our company offers variety of products which can meet your multifarious demands.We adhere to the management principles of "quality first, customer first and credit-based" since the estab lishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.

Our Advantages Representative products

Production Product advantages

Solar CellAnti-PIDHigh conversion efficiencyNo color difference A grade	EVAAnti-PIDExcellent transmittance,ensure high efficiency of PV components;Excellent aging resistance,low yellowwish change;Less bubble for solar cell encapsulation	Junctlon BoxTUV solar connector PV MC4IP 67(bypass diode)Temperature Range:-40~+90C(PE Cable-40!+85C)Protection Class:llFlame ClassUL94-V0	Aluminum FrameAnti-corrosion,oxidation resistance;Strength and solid and strong.Strong tensile properties,Life 30-more than 50 years,Silver or black frames are optional	Front GlassLow iron ultra clear tempered glass with 93% transmittancecan resist the hail effectivelyThickness=3.2mmAntireflective glassService life is as long as 25years

Product related components Product project case

Payment Term	T/T	EXW	30% T/T in advance, paid the balance before shipment
		FOB
		CFR(C&F)	30% T/T in advance, paid the balance against copy of B/L
		CIF
	L/C	L/C amount above 50,000 usd, we can accept L/C at sight
	PayPal	Amount lower than 3000usd
	PayPal
Delivery Time	17~20days after receiving payment for one container

FAQ
